- Large format with rigid acrylic face.
- Easy graphic change via hinged profile.
- Even backlit LED illumination.
- Robust aluminium profiles.
- Depth from only 55mm.
- Single or double sided.
- Bespoke sizes made to order.
‘Hercules’ LED Light Box
Out of stock
Description
The Hercules LED hinged frame light box has been developed for large format illuminated display graphics with rigid acrylic fascias. They come with an easy to operate hinged frame which allows easy graphic changing even at larger sizes.
The hinged frame opens on all four sides which allows access to the clear acrylic front sheet, the backlit print and the opal diffuser. The print can then be easily changed and the four hinged profiles closed up again to hold the print and panels in place. The secure frame profile allows the Hercules to be made in larger sizes than standard snap frames.
Hercules light boxes can be made in custom colours and sizes up to a maximum size of 3000mm x 2000mm and are available from a depth of only 55mm. There is also the option of having a double sided light box at 170mm depth.
The Hercules hinged frame light box evenly illuminates the graphic using LED strips spaced evenly across the back panel according to the depth of the light box to ensure optimum light spread.
W&Co supplied and installed a large format ‘Hercules’ LED Light Box for a clinical CT scan room at Queen Alexandra Hospital in Portsmouth.
Specification
- Dimensions: Custom sizes up to 3m x 2m.
- Depth: 55mm, 100mm, 130mm single sided (can also be made double sided at 170mm deep).
- Frame: 19mm, 30mm, 35mm wide hinged cover profile.
- Back Panel: 1mm aluminium plate.
- Colour: Silver anodised aluminium as standard or RAL colours and special finishes are available at an additional cost.
- Front Cover: 3mm clear acrylic sheet (anti-glare option available on request).
- Diffuser: 3mm opal acrylic panel.
- Illumination: Backlit with LED strips.
- Print: Lambda Duratrans or Backlit posters.
- Accessories: Cable suspension kits, freestanding feet and base plates available.
- Certification: This product is CE and RoHS Certified.
Prices
Prices available upon request so please feel free to fill out our Free Quote form or give us a call with your requirements.
